| Processorproducent | Intel |
| Processorserie | Intel® Xeon® |
| Processormodel | L3406 |
| Processorens basisfrekvens | 2,26 GHz |
| Processorkerner | 2 |
| Processor sokkel | LGA 1156 (Socket H) |
| Processor litografi | 32 nm |
| Kasse | Yes |
| Køler inkluderet | Yes |
| Komponent til | Server/arbejdsplads |
| Processorserie | Intel Xeon 3400 Series |
| Processortråde | 4 |
| Systembus-hastighed | 2,5 GT/s |
| Processor driftstilstande | 64-bit |
| Processor boost frekvens | 2,53 GHz |
| Processor-cache | 4 MB |
| Processor cache type | Smart cache |
| Thermal Design Power (TDP) | 30 W |
| VID spændingsområde | 0,65 - 1,4 V |
| Kompatible chipsæt | Intel® 3400, Intel® 3420, Intel® 3450 |
| Stepping | C2 |
| Bus type | DMI |
| CPU-multiplikator (bus/kerneforhold) | 17 |
| Hukommelsesbåndbredde understøttet af processor (maks.) | 17 GB/sek. |
| Processor kodenavn | Clarkdale |
| Processor kode | SLBQQ |
| Processor ARK ID | 47555 |
| Maksimal intern hukommelse understøttet af processor | 16 GB |
| Hukommelsestyper understøttet af processor | DDR3-SDRAM |
| Hukommelsesurhastigheder understøttet af processor | 1066 MHz |
| Hukommelseskanaler | To-kanals |
| Fejlkorrigerende kode | Yes |
| On-board grafikkort | No |
| Udfør deaktivering af bit | Yes |
| Idle status | Yes |
| Termiske overvågningsteknologier | No |
| Markedssegment | Server |
| Maksimalt antal PCI Express-kanaler | 16 |
| PCI Express slots version | 2.0 |
| PCI Express-konfigurationer | 1x16, 2x8 |
| Antal behandling Die transistorer | 382 M |
| Behandling Die størrelse | 81 mm² |
| Antal grafik og IMC Die transistorer | 177 M |
| Grafik og IMC Die størrelse | 114 mm² |
| Understøttede instruktionssæt | SSE4.2 |
| Fysisk adresseudvidelse (PAE) | Yes |
| CPU-konfiguration (maks.) | 1 |
| Indlejret tilgængelige muligheder | No |
| Grafisk og IMC litografi | 45 nm |
| Fysisk adresse udvidelse (PAE) | 36 Bit |
| PCI Express CEM-revision | 2.0 |
| Eksportkontrolklassisfikationsnummer (ECCN) | 3A991 |
| Automatiseret sporingssystem til vareklassificering (CCATS) | NA |
| Billedtypekort | |
| Intel® Hyper Threading Teknologi (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Teknologi | 1.0 |
| Intel® AES Nye Instruktioner (Intel® AES-NI) | No |
| Enhanced Intel SpeedStep Teknologi | Yes |
| Intel® Trusted Execution Teknologi | Yes |
| Intel® Enhanced Halt State | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Demand Based Switching | Yes |
| Intel® 64 | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Berettigelse til Intel® vPro™ platform | No |
| Tcase | 53,9 °C |
| Pakkebredde | 81 mm |
| Pakkedybde | 114 mm |
| Pakkehøjde | 102 mm |
| Pakkevægt | 394 g |
| Pakketype | Detailboks |
| Processor cache | 4096 KB |
| Produkttype | Processor |
| Understøttede hukommelsestyper | DDR3-SDRAM |
| Fødselsdato | Q1'10 |
| Bus båndbredde | 2,5 |
| Bustype enheder | GT/s |
| Lanceringsdato | Q1'10 |
| Processor kernespænding | 0.6500-1.400 V |
| Produktnavn | Intel Xeon L3406 (4M Cache, 2.26 GHz) |
| Status | Discontinued |
| Maksimal hukommelse | 16,38 GB |
| Processor brand navn | Intel Xeon |
| Sidste ændring | 63903513 |
| Produktfamilie | Intel Xeon Processor 3000 Sequence |
| Bushastighed | 2.5 GT/s |
| Harmoniseret systemkode (HS) | 85423119 |
| Processor-pakke størrelse | 37.5 x 37.5 mm |
| Intel® Virtualization Teknologi (Intel® VT) | VT-d, VT-x |
| Maksimal intern hukommelse | 16,38 GB |
| Maksimal intern hukommelse | 16777 MB |
| Cache hukommelse | 4 MB |
